Double Drum
45-Meter Cable
Motorized Chassis
The M45D features a double-drum design, making it ideal for dual-cable operations. Seamlessly integrating with 400Hz GPUs, it enhances efficiency, improves safety, and ensures clean, organized apron management in modern airports.
Easy M&O
The motorized system reduces manual labor and enhances work efficiency.
Automatic Protection
Full-process monitoring during cable coiling. Synchronized control between the motorized chassis and the cable system enables cable coil in and out while in motion. A built-in limit sensor prevents over-retraction of the cable.
Slip Ring Anti-Twist
Prevents cable twisting during rotation, ensuring smooth cable handling and effectively protecting the 400Hz power cable, extending its service life.
| Rated voltage | 220V | |
| Rated frequency | 50Hz | |
| Connection mode | L+N | |
| 400Hz AC | ||
| Rated voltage | 115V/200V | |
| Rated capacity | 90kVA | |
| Rated frequency | 400Hz | |
| Rated current | 261A | |
| Protect | ||
| Take-up terminal limit protection | Available | |
| Pay-off terminal limit protection | Available | |
| 400Hz plug insertion interlock protection | Available | |
| Overcurrent protection | Available | |
| Overvoltage protection | Available | |
| Overload protection | Available | |
| Environment | ||
| Operating temperature | -20℃~50℃ | |
| Relative humidity | 0～100%(no condensation) | |
| Structure | ||
| Dimensions(L*W*H) | 1700*1030*1450mm | |
| Weight | 650kg(with 45m cable) | |
| Other | ||
| Protection degree | IP54 | |
